SW520 Ball Switch
Buying option
takealot.com
Best Deal
In stockThe Story
The SW520D Roller Ball Tilt Switch is a simple motion or orientation sensor that uses a brass housing encased in shrink tubing to prevent short circuits. When the sensor is oriented with leads facing downward, a metal ball rolls onto the poles, completing the circuit. Ideal for basic tilt detection applications, this switch offers a contact rating of 12V and operates at angles between 30-90 degrees from horizontal.
add_circle The Upside
- check Simple and cost-effective tilt detection
- check Easy to integrate with no polarity concerns
- check Compact and durable design
remove_circle The Downside
- close Less accurate than accelerometers
- close Limited to on/off tilt detection
- close Not suitable for precise angle measurement
Specifications & features
Key features
- check_circle Brass housing with shrink tubing for short circuit prevention
- check_circle Roller ball mechanism for tilt detection
- check_circle Contact rating: 12V, max current: 30mA
- check_circle Operates at 30-90 degrees from horizontal
- check_circle Pins have no polarity, can be interchanged
Specifications
Activation Angle
30-90 degrees from horizontal
Capacitance
5PF
Contact Rating
12V
Contact Resistance
Not specified
